Extrusion Blow Moulding Machines



SINGLE STATION & DOUBLE STATION EXTRUSION BLOW MOULDING MACHINES 250 ml - 15 litre
EXTRUDER
-
250/SS
250/DS
500/SS
500/DS
1000/SS
1000/DS
2000/SS
2000/DS
5000/SS
5000/DS
10000/SS
15000/SS
Screw Diameter
mm
30
30
30
40
40
50
50
60
65
75
70
75
L/D Ratio
L/D
22:1
22:1
22:1
22:1
22:1
22:1
22:1
22:1
22:1
22:1
22:1
22:1
Extruder Motor Power D /C A/c
kW
3.75
3.75
3.75
5
7.5
15
15
20
20
30
20
30
Screw Speed
RPM
25-100
25-100
25-100
25-100
25-100
15-75
15-75
15-75
15-75
15-75
15-75
15-75
Extruder Heat. Power
kW
3
3.5
3.5
4
7
9
9
11
15
20
18
20
Extruder Heat. Zone
n°
3
3
3
3
5
5
5
6
7
8
7
8
Extruder Cooling Fan
n°
2
2
2
2
3
3
3
4
-
-
-
-
PE Plasticising Capacity
kg/h
8-9
10-11
10-11
21-22
20
30-32
30-32
40-42
60
100
75
100
PVC Plasticising
kg/h
4-5
7-8
7-8
16-18
16
24
24
30
-
-
-
-
BLOWING UNIT
Heating Zone 1
n°
2
2
2
2
2
2
2
2
2
2
2
2
Single Head Die Dia.
mm
25
25
35
35
70
70
90
90
150
150
160
180
Double Head Die Dia.
mm
-
-
-
-
45
45
55
55
65
65
75
75
Centre Distance Double Head
mm
-
-
-
-
100
100
120
120
165
165
165
180
Hollow Body Max. Vol.
cc
250
250
500
500
1000
1000
2000
2000
5000
5000
1000
15000
Container Dia.Max.
mm
60
60
80
80
125
125
150
150
200
200
220
300
Max. Mould Clamp. Force
kN
15
15
15
15
25
25
40
40
55
55
60
75
MOULD
Height
mm
175
175
250
250
300
300
350
350
450
450
525
560
Width
mm
125
125
150
150
200
200
250
250
300
300
350
520
Thickness (Min.)
mm
125
125
180
180
180
180
205
205
275
275
310
360
Opening stroke
mm
125
125
180
180
175
175
200
200
250
250
300
350
Mould Cooling (PE)
kJ/h
700
700
700
700
700
700
700
700
700
700
700
700
Water Consumption at 28°C
m3/h
0.5
0.6
0.5
0.7
1-1.5
1.5-2
1.5-2
2-3
2-3
3-4
4-5
4-5
GENERAL
Total Installed Power
kW
6.75
8.5
8.5
11.5
18.25
29
29
38.5
42.5
57.5
57.5
61
Comp. Air Pressure
bar
6-8
6-8
6-8
6-8
6-8
6-8
6-8
6-8
6-8
5-7
5-7
6-8
Com. Air Consumption
1/min.
500
500
700
700
400
600
600
800
800
1200
1200
1600
Cooling Water Pressure
bar
2-3
2-3
2-3
2-3
2-3
2-3
2-3
2-3
2-3
2-3
2-3
2-3
Oil Operation Pressure
bar
-
-
-
-
120
120
120
120
120
120
120
140
Oil Tank Capacity
1
-
-
-
-
100
100
100
150
150
200
200
300
Oil Pump Motor Power
HP
-
-
-
-
5
7.5
7.5
10
10
10
10
15
